EMO-6-X 6A 250V Power Socket

No reviews
  • Share
  • Tweet
Product SKU: CON-17549
Available:
Only 0 item in stock
0 item in stock
In stock
Pre-order
Out of stock
₹ 0.00 (Incl.Tax)

This item is a recurring or deferred purchase. By continuing, I agree to the cancellation policy and authorize you to charge my payment method at the prices, frequency and dates listed on this page until my order is fulfilled or I cancel, if permitted.
Notify me When Available
You will receive an email when the product is available.
Want it delivered by
For Bulk Enquries:
+91 90614 50999
  • Description
  • Specifications
  • Applications
  • Usage Notes
  • Reviews

The EMO‑6‑X is a compact IEC-style power inlet socket rated at 6 A and 250 V AC, ideal for lightweight power applications. Featuring a snap‑in panel design and compliance with IEC 60320‑1 standards, this socket offers reliable and safe electrical connections for small appliances, test equipment, and DIY electronics enclosures.

  • Rated Voltage/Current: 250 VAC, 6 A
  • Standards: IEC 60320‑1 compliant
  • Contact Resistance (initial): ≤ 10 mΩ
  • Insulation Resistance @ 500 V DC: ≥ 1000 MΩ
  • Dielectric Strength (1 min): 2 kVAC
  • Mounting Style: Panel snap‑in
  • Available Terminals: Solder, Fast‑on, or PCB
  • Operating Temperature: –25 °C to +70 °C
  • Body Material: Nylon‑6 GF20% (UL V‑2); Contacts: Brass, tin‑plated
  • Panel Cutout Size: approx. 20 × 30 mm (confirm with datasheet)
  • Panel-mount inlet for small power supplies and adapters
  • Embedded electronics requiring detachable power cord
  • Appliance replacement inlet for low-current devices
  • Chassis mounting in DIY or lab equipment
  • Verify panel thickness compatibility for snap-in fit.
  • Select terminal style based on assembly method (solder, Fast‑on, PCB).
  • Ensure wiring and fuses are rated for 6 A to meet safety standards.
  • Maintain ambient operating temperature within rating for longevity.
  • Follow soldering guidelines to maintain the integrity of the housing.
